CVD-060 Small Freeze Dryer | 0.6m² Drying Area · 6kg/batch · 220V Power

0.6m² shelf area, 6kg dry output per batch, runs on standard 220V household power. 50% more capacity than the CVD-040 for a modest price increase — the best value in the small freeze dryer lineup.

Overview

The CVD-060 is a compact vacuum freeze dryer from Yuanxian Machinery designed for home users, labs, and food startups. With 0.6m² of drying area, each batch produces approximately 6kg of dry product (equivalent to 30~40kg fresh input). It runs on 220V/50Hz single-phase power and occupies less than 1m² of floor space.

Compared to the CVD-040, the CVD-060 offers 50% more shelf area, a colder cold trap (≤ -50°C), and better ultimate vacuum (≤ 10Pa), enabling processing of a wider range of materials with more consistent results.

Key Specifications

Applications

Advanced home use — For users who outgrew the CVD-040. 6kg/batch handles larger volumes of fruits, vegetables, and meats.

Small laboratory — Food R&D, process validation, and new recipe testing. Compact footprint fits on a lab bench.

Food startup entry — 12 batches per day (612kg dry output) for freeze-dried pet treats, fruit tea ingredients, or instant coffee.

Selection Guide

The CVD-060 is the “sweet spot” model — 50% more capacity than the CVD-040 at a modest price premium. For 3+ batches daily or continuous operation, upgrade to the CVD-100.

FAQ

Q: What’s different from the CVD-040? A: 50% more drying area (0.4→0.6m²), colder cold trap (-45→-50°C), and better vacuum (20→10Pa) for more consistent results across a wider range of materials.

Q: Can a standard 220V outlet power it? A: Yes. Total power draw is ~1.8kW — a standard 220V/10A outlet is sufficient. No 380V industrial wiring needed.
